UK6N modular terminal block
| Manufacturer | HANGZHOU BALIANFANG STANDARD PARTS CO.,LTD |
| Model Number | UK 6N |
| Type | Screw Terminal |
| Length/Height/Wide(mm) | 42.5/47/8.2 |
| Rated current | 57A |
| Rated voltage | 800V |
| Application | Wire Connecting |
| Conductor Size | 24-10 AWG |
| a fixed way | NS 35 / 7.5 rail fixed |
| Standard | IEC 60947-7-1 |
| LOGO | Customized logo are supported |
| Certificate | ISO9001/CE/ROHS/CQC |
| Color | Gray /Blue/Yellow/Green/Black/wine Red/Orange red/ Customized |
Features:
The internationally recognized screw connection meets the most stringent requirements and covers a wide area of application. For the most stringent requirements: the screw connection has also proven itself in the wiring of large conductor cross section
- The JUK universal screw terminal block series has the typical features which are decisive for practical applications.
- Made from engineering flame retardants nylon PA66 with brass screw metal.
- With universal foot which can be installed on Din Rail NS 35.
- It can connect two conductors with ease, even large conductor cross sections are not a problem.
- Electric potential distribution can use fixed bridges in the terminal center or insertion bridges in the clamping space.
- All types of accessories: End cover, End Stopper, Partition plate, marker trip, fixed bridge, insertion bridge, etc.
| FAQ: |
| 1.Are you factory or trading company? |
| Yes,we are manufacturer in zhejiang,China. We can give you the competitive price & after sale service. |
| 2.Could I print my own logo on the bag? |
| Yes,your logo can be printed as your demand. we can offer OEM service. |
| 3.What terms of payment & price condition & do you accept & use? |
| Payment terms:T/T,.LC,Paypal,Western union.etc. Price condition:FOB(Shanghai & Ningbo).EXW,C&F etc. |
| 4.What money do you accept for wire transfer? |
| USD,CNY/RMB,EURO etc. |
| 5. How many days will it take to delivery the goods? |
| It denpends on your order quantity,small quantity will delivery the goods in 7-10days, if your order is big enough,it will take 10~15 days to make and delivery it. |
