Shunt resistors are used to measure currents that would potentially damage an ammeter.
Packing: Standard Seaworthy packing
15-20 KG/Carton
A shunt resistor typically looks different from a normal resistor, having two large terminals with one or more strips of metal connecting them.
Following the slogan of quality first, customers first, reputation first, we have the confidence that we will go further and higher!
Please feel free contact with us!
Manganin Copper Shunt Resistor is a copper-manganese resistance alloy used as shunt in various high current applications. The alloy has a low temperature coefficient of resistivity with a peak resistance of approximately 50°C. The thermal EMF is very low compared to copper.
The alloy can be easily formed from the annealed condition. The maximum recommended operating temperature in air is 200°F.
Wide Operating Temperature Range: This product operates within a wide temperature range of -40°C to +60°C, making it suitable for use in harsh environments and applications where temperature fluctuations are common.
High Overload Capacity: The shunt resistor has an overload capacity of 120% of its rated current for 2 hours, providing added protection and reliability in case of temporary overloads.
Durable Construction: Made from a metal alloy of brass and manganin, this shunt resistor is built to last, withstanding high humidity levels of up to 95% and ensuring consistent performance over time.
Customizable Options: Available in various current ratings (1A to 1000A) and voltage drops (50mV, 75mV, 100mV, 200mV), this product caters to diverse user needs and applications, including DC current shunt resistor and watt meter shunt resistor applications.
The quality of our Super resistance alloy, 50H, precision wire represents the survival of the enterprise and the production represents the progress of the enterprise. We have fundamentally realized the three-dimensional strategic innovation model. We are willing to cooperate with customers sincerely with diversified choices and considerate service to achieve multi win!
